- Size：DN25-DN100 (1"-4")
- Max. working temperature:120℃(EPDM), 150℃(PTFE)
- Max. working pressure: 0.6MPa
- Connection type: weld, clamp, flange, thread
- Piping standard: ISO, SMS, DIN, IDF/3A
- Can be used in vertical or horizontal position
- Material contacted with media: stainless steel 304 or 316L+Boron silicate glass
- Material of protective sleeve: stainless steel 304
- Material of gasket: Silicon rubber, PTFE
- Surface treatment: Matte
